F030 Safe Area / Intrinsically Safe Batch Controller
Manufacturer: Precision Digital
Images are representations only.
F030 Safe Area / Intrinsically Safe Batch Controller
Manufacturer: Precision DigitalThe F030 is a straight forward but easy-to-use batch controller.
The operator can easily enter a batch quantity or execute repeating batches.
During the batch, the preset value is displayed as well as the batched (or remaining) quantity and the units of measurement.
The automatic self-learning overrun correction will ensure an accurate batch every time.
On-screen engineering units are easily configured from a comprehensive selection.
Features- Large display shows preset value and running batch value simultaneously
- LED backlight option
- Count-up and count-down function available
- Selectable on-screen engineering units; volumetric or mass
- Self-learning overrun correction
- Easy operation to enter a batch value and to control the process
- Ability to process all types of signals: Sine wave (coil), NAMUR, NPN/PNP pulse, Reed-switch, Active pulse signals, (0)4-20 mA
- One control output for one-stage batching
- Power requirements: Input loop powered, battery powered or 8-30 VDC, 24 VAC/DC and 115-230 VAC
- Sensor supply: 3.2 / 8.2 / 12 / 24 VDC
- Auto backup of settings and running totals
- Explosion/flame proof available, according ATEX/IECEx
Advantages
- Robust aluminum or stainless steel 316L field enclosure (IP65, IP67 / NEMA Type4X). It is so rugged, a truck can even stand on it!
- Intrinsically Safe available - ATEX, IECEx and CSA approval for gas and dust applications
- Familiar easy operation with the Fluidwell "Know one, know them all" configuration structure, saving time, cost and aggravation
- Very diverse mounting possibilities: walls, pipes, panels or directly onto outdoor sensors
Specifications
Manufacturer
Operating Temperature
- -40° to 80° C (-40° to 176° F)
Display
- High intensity reflective numeric and alphanumeric LCD, UV-resistant
- Seven 17 mm (0.67”) and eleven 8 mm (0.31”) digits. Various symbols and measuring units
- User definable: fast, 1sec , 3sec, 15sec, 30sec, off
Power Requirement
- Type PB: Long life Lithium battery
- Type PC: Intrinsically Safe long life lithium battery
- Type PD: 16-30 VDC
- Type PF: 24 VAC / DC ± 10%, Power consumption max. 15 W
- Type PL: Input loop powered from sensor signal 4-20 mA (type “A”)
- Type PM: 115-230 VAC ± 10%, Power consumption max. 15 W
- Type PX: 8-30 VDC. Power consumption max. 0.3 W
- Type ZB: 20-30 VDC ± 10%. Power consumption max. 1 W. With type PF / PM: internally powered
Terminal Connections
- Removable plug-in terminal strip. Wire max. 1.5 mm2 and 2.5 mm2
Mounting
- GRP, Aluminum or Stainless Steel Wall / field mount
- Panel Mount
Accuracy
- Error < 0.01 mA / ± 0.05 % Full Scale
Resolution
- 16-bits
Enclosure
- Polycarbonate Window
- Sealing: Silicone
- Control keys Three industrial micro-switch keys. UV-resistant silicone keypad
Environmental Protection
- IP65
- IP67
- NEMA 4X / IP65, 67
Approvals & Certifications
- RoHS
- IP & NEMA
- Low Voltage Directive 2014/35/EU
- EMC
- ATEX
- CE
- CSA
- FM
- IEC
- IECEx
Signal Inputs
- Flowmeter Pulse type inputs: Reed-switch, NAMUR, NPN/PNP pulse, Sine wave (coil), active pulse signal
- Flowmeter: (0)4 – 20mA
Signal Outputs
- Control outputs - Function: Control output for one-stage batching with active overrun correction
- Control outputs - Type: One passive NPN transistor, active PNP transistor or isolated electro-mechanical relay
Communication
- Modbus
- HART
- For One Stage Batch Qpplications at Low or Medium Flow Rates with Single or Repeating Batches
- For Field Mount Indicators in Safe and Hazardous Area Applications. Especially in Harsh Weather Conditions Like Rain, Snow, Sandy Deserts, Salty Atmospheres and Temperatures Between -40° to +80° C (-40° to 176° F)
