FPBA-01 PROFIBUS DP Adapter Module
Manufacturer: ABB
Images are representations only.
FPBA-01 PROFIBUS DP Adapter Module
Manufacturer: ABBThe F-series FPBA-01 is a PROFIBUS DP adapter module supporting DP-V0 and DP-V1 communication.
The FPBA-01 automatically detects the telegram type used, and supports both PPO messages 1 to 8 and standard telegrams (STD) 1 and 2.
Communication profiles PROFIdrive, ABB drives, Transparent 16-bit and Transparent 32-bit are supported.
FPBA-01 is compatible with ACS580, ACS480, ACS380, ACH580, ACH480, ACQ580, ACS355, ACSM1 and ACS880 drives.
Documentation
Manual
- ABB Drives function blocks for Siemens PLC’s - Quick start-up guide pdf 6.5 MB
- Basic Guide to Communications PTO (Profibus DP, Profinet I/O), US pdf 5.5 MB
- DCS880 PROFIBUS communication via FPBA-01 pdf 1.6 MB
- DCT880 PROFIBUS communication via FPBA-01 pdf 904 KB
- FPBA-01 PROFIBUS DP adapter module quick guide pdf 303 KB
- FPBA-01 PROFIBUS DP adapter module user's manual pdf 4.4 MB
