MOD-VENT Ventilation Kit Enclosure Modification

Manufacturer: Precision Digital

MOD-VENT Ventilation Kit Enclosure Modification

Manufacturer: Precision Digital
The PDA0007 ventilation kit consists of two vents and is designed to equalize internal / external pressure and temperature to prevent condensation from building up in the enclosure.

Internal baffles within the vents create an airflow pattern that allows air to pass between the inside of the enclosure and the outside environment.

The vents are rated UL & CSA Type 4X and IP66.

The ventilation kit can also be ordered as a MOD-VENT-P for plastic enclosures and a MOD-VENT-M for steel enclosures.

When this is done, the accompanying enclosure will be provided with pre-drilled holes for the vents (Installation is done by the user and the enclosure is sold separately).
Features
  • Prevents Condensation Inside the Enclosure
  • UL & CSA Type 4X IP66
  • Plastic and Steel Enclosures Available with Mounting Holes Pre-Drilled
  • For Wall Thickness of 16 Gauge to 1/4"
  • Corrosion Resistant Polycarbonate
  • Comes with two vents
  • Installation Template Included
  • Hardware Included

Specifications

Manufacturer

Ingress Protection

  • Type 1, 3R,4, 4X IP66

Certifications & Approvals

  • UL & CSA

Material of Construction

  • Injected Molded Polycarbonate

Colour

  • Gray

Gasket Material

  • (FIP) Polyurethane

Operating Temperature

  • -35° to 130° C (-31° to 266° F)

Outdoor Rating

  • UV Rating (f1) per UL 746C-UV Stabilized

DimensionS (H x W x D)

  • 4.17" x 2.96" x 0.75"
  • 106 mm x 75 mm x 19 mm
